Stainless steel interior with solid anthracite aluminium elements
Warm white and glare-free LED light spots
Opening assist for door with two options:
1. Push-to-open function for integration into handleless furniture front
2. Pull-to-open function to facilitate opening the door using a handle
Handling
TFT touch display operation.
Clear text display.
Features
Dynamic cold air distribution.
Automatic defrosting with defrost water evaporation.
Rest mode certified by Star-K.
When rest mode is active, the appliance can only be opened using a handle.
Open-door and malfunction alarm.
Integrated WiFi module for digital services
(Home Connect).
The availability of the Home Connect functionality depends on the availability of the Home Connect Services in your country. Home Connect Services are not available in every country – for further information please check: www.home-connect.com
Freezing
No-frost technology with fast freezing at -30 °C.
Temperature adjustable from -14 °C to -24 °C.
4-star freezer compartment.
Freezing capacity 18 kg/24 h.
Storage time after a malfunction 13 h.
4 safety glass shelves, 3 of which are individually height adjustable.
2 fully extendable drawers with transparent front.
Smooth design door rail system with fully flexible positioning of door racks.
4 height-adjustable door racks.
Ice maker
Integrated in the freezer compartment, with fixed inlet water connection.
Particle filter for water inlet, integrated in ventilation grille area.
Can be switched off.
Ice cube production approx. 1.5 kg/24 h.
Removable ice storage container with approx. 4 kg capacity.
Product rating
Energy efficiency class A++ at a range of energy efficiency classes from A+++ to D.
Energy consumption 284 kWh/year.
Noise level 42 dB (re 1 pW).
Planning notes
Flat hinge.
Door opening angle of 115°, fixable at 90°.
For installation with a door opening angle of 90° the ice storage container must be exchanged for the small ice storage container (RA 448220). This must be done prior to fixing the door.
Max. door panel weight 25 kg.
Shut-off valve for water connection must be planned next to the appliance and always be accessible.
If the water pressure exceeds 0.8 MPa (8 bar), connect pressure relief valve between water tap and hose set.
Connection
Total connected load 0.300 KW.
Connecting cable 3.0 m, pluggable.
Water inlet.
Supply hose 2.0 m with 3/4 ” connection.
Water pressure 2.4 to 8.3 bar.
Door hinge left, reversible.
